1000 Ton Plastic Injection Mould Machine , 380v 50hz Injection Making Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Sailai |
| Certification: | ISO9001 |
| Model Number: | SL230 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Export Standard |
| Delivery Time: | 25 days |
| Payment Terms: | TT, L/C, Western Union |
| Supply Ability: | 500sets/month |
|
Detail Information |
|||
| Shot Weight: | 361/446/540grams | Ejector Point: | 5 |
|---|---|---|---|
| Machine Dimension: | 5.6m*1.5m*2.3m | Tie Bar: | 520*520mm |
| Machine Weight: | 6500KG | Type: | 230 Injection Molding Machine |
| High Light: | horizontal injection molding machine,plastic products making machine |
||
Product Description
230tons best price ISO9001T-slot PET preform bottle high speed energy saving PP PE plastics injection molding machine
home appliance injection molding machine is the type of fully-automatic machine, being provided with high efficiency, high reliability, high speed, low noise, low power consumption and other advantages
Machine main components adopt world famous brand, e.g.:
• PLC: TECHMATION CONTROLLER(Taiwan)
• AC Contactor: SIEMENS(Germany)
• Travel switch: SCHNEIDER(FRANCE),
• Transducer: NOVOTK (Germany)
• Proportional Valve: HNC(TAIWAN)
• Oil pump: VICKERS(USA)
• Directional Valve: VICKERS(USA)
• High-pressure pipe line: GOOD YEAR (USA)
Main technical parameters
| Product Name | 230 Injection molding machine price |
| Capacity | 10-15 cartoon/min |
| Table height | 800mm |
| Applicable size | (L)300-400×(W)300-450×(H)100-200 |
| Machine size | (L)5.6m×(W)1.5m×(H)2.31m |
| Machine weight | 6500KG |
| Rated power | 4KW |
| Power supply | 380V 50HZ |
| Air supply | 150L/min 6Mpa |
| Hot melt adhesive | curing time 2-3 seconds,working temperature: 150-180°C |
Characteristics
1. Adopts the imported control components, durable, safe, and low failure rate.
2. Use human-computer interface, simple and more visually oriented.
3. The machine uses machine electrical and air linkage, excellent effect of bottom sealing.
4. East to adjust different sizes of cartons, adjust quickly and easily, available for a wide range of cartons.
5. Low power consumption, simple and convenient operation, low noise.
6. Use tap to seal the cartoon bottom, protected from weather, sealing reliable.
Specification
| SL230 | A | B | C | |
| INJECTION UNIT | ||||
| SCREW DIAMETER | mm | 45 | 50 | 55 |
| SCREW L/D RATIO | L/D | 24.4 | 22.0 | 20.0 |
| SHOT SIZE(THEORETICAL) | cm³ | 397 | 490 | 593 |
| INJECTION WEIGHT(PS) | g | 361 | 446 | 540 |
| INJECTION PRESSURE | Mpa | 219 | 177 | 145 |
| CLAMPING UNIT | ||||
| CLAMPING FORCE | Kn | 2300 | ||
| TOGGLE STROKE | mm | 475 | ||
| SPACE BETWEEN TIE BARS | mm | 520*520 | ||
| MAX.MOULD HEIGHT | mm | 560 | ||
| MIN.MOULD HEIGHT | mm | 200 | ||
| EJECTOR STROKE | mm | 150 | ||
| EJECTOR TONNAGE | Kn | 70 | ||
| MAX.TEMPLATE SPACE | mm | 1035 | ||
| DIE HOLE DIAMETER | mm | 160 | ||
| EJECTOR NUMBER | PC | 9 | ||
| OTHERS | ||||
| MAX.PUMP PRESSURE | Mpa | 16 | ||
| TEMPERATURE CONTROL | paragraph | 3+1 | ||
| MACHINE DIMENSION(L*W*H) | m | 5.6*1.5*2.3 | ||
| MACHINE WEIGHT | Ton | 6.5 | ||
| OIL TANK CUBAGE | L | 300 | ||
FAQ:
1: What is your fast develiver time?
A: According to the machine,our production time is generally 20 days.
2: What are your trade terms and payment terms?
A: Trad terms: FOB Ningbo
Payment terms:30% T/T in advance, balance before shipment.
3: How long is your machine warranty?
A:18 Months guarantee when the machine arrival your factory.
