• 16 Cavities Plastic Injection Molding Machine 150L/Min 6Mpa 240T
16 Cavities Plastic Injection Molding Machine 150L/Min 6Mpa 240T

16 Cavities Plastic Injection Molding Machine 150L/Min 6Mpa 240T

Product Details:

Place of Origin: China
Brand Name: taihong
Certification: ISO9001
Model Number: HJF780

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Export Standard
Delivery Time: 25 days
Payment Terms: TT, L/C, Western Union
Supply Ability: 500sets/month
Get Best Price Contact Now

Detail Information

Shot Weight300rams: 264/317/375grams Ejector Point: 5
Machine Dimension: 4.85m*1.3m*2.1m Tie Bar: 470*470mm
Air Supply: 150L/min 6Mpa Capacity: 10-15 Cartoon/min
High Light:

horizontal injection molding machine

,

plastic products making machine

Product Description

16 Cavities Plastic Injection Molding Machine 150L/Min 6Mpa 240T

Pet preform molding , Plastic Injection Molding Machine 150L/Min 6Mpa , 16cavities 240T plastic machine



1.Any inquires will be replied in the first time.

2.High quality products, competitive price, fast lead time.

3.Our sales staff will be have a good communication with you ,let you fully understand the situation of our enterprises and products.

4.We will provide high quality overseas service ,our technical staff will be able to provide you with technical support ,for you personally to overseas assembly and test equipment.

5.Our customer service staff will put your feedback to the technical staff in the first time, timely solve your problem.


Characteristics



1. Adopts the imported control components, durable, safe, and low failure rate.

2. Use human-computer interface, simple and more visually oriented.

3. The machine uses machine electrical and air linkage, excellent effect of bottom sealing.

4. East to adjust different sizes of cartons, adjust quickly and easily, available for a wide range of cartons.

5. Low power consumption, simple and convenient operation, low noise.

6. Use tap to seal the cartoon bottom, protected from weather, sealing reliable.



Product name High quality moulds for injection plastic injected molding handle
Plastic material PP, PC,PVC, Silicone,Rubber,PPA, ABS, PE, Acrylic,POM, PA6,HDPE, etc.
Steel of cavity and core

Commonly used material as below:

SCHMOLZ: P20HH, 2738, 2083H,2343, 2344, etc.

DIN: 1.2738,1.2083, 1.2343, 1.2344, 1.3343, etc.

AISI: P20, H13, D2, D6, M2, etc.

ASSAB: 718HH, Nimax, 8402, 8407, XW-10, XW-5, EM2, etc.

Japanese: HPM2, NAK80, SKD61, SKS3, SKD11, DC53, SKH51, etc.

Runner

1.Hot Runner: (Synventive from Netherland) or as your requests.

2.Cold Runner.

Mold life

Commonly used:

1. 300,000-500,000 shots for 1 year under normal use prodcedure for pre-hardness steel material.

2. 5.00,000 shots for 1 year under normal use prodcedure for heat treatment steel material.

Delivery time

Depends on the size and structure.

Normally: 25-30 working day.

Machine center High speed CNC, Wire cutting, EDM, Grinder, Great Grinder, CNC milling, Drilling and milling, Stamping punching machines, injection machine, Inspection.
R&D

1. Drawing design and making for products and mold;

2. Mold drawing revising;

3. Production time and quality control in each machining process.

16 Cavities Plastic Injection Molding Machine 150L/Min 6Mpa 240T 0

Specification



Injection Unit UNIT A B C D
Screw diameter mm 90 95 105 110
Screw L/D ratio L/D 23.2 22 19.9 19
Shot size(theoretical) CM³ 2924 3258 3981 4369
Injection weight(ps) g 2632 2933 3583 3932
Injection rate g/s 574 640 781 858
Injection pressure Mpa 195 175 143 130
Screw speed rpm 115
Clamping Unit
Clamp tonnage KN 7800
toggle Stroke Mm 950
Space Between tie Bars mm 980*950
Max.mold height mm 960
Min.mold height mm 400
Ejector Stroke Mm 280
Ejector tonnage KN 186
Others
Max.pump pressure Mpa 16
Pump motor power KW 37+30
Heater power kw 56.7
Machine size(L x W x H) m 11.43*2.4*3.14
Machine weight Ton 37
Oil tank capacity L 1500



Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
